Model NO. D001010002D
Min. Order 1 Piece
Port Ningbo, China
Production Capacity 100sets/Month
Payment Terms L/C, T/T, D/P, Western Union, Paypal, Money Gram
Certification ISO9001
Media Water
Standard Standard
Connection Mode Welding
Power Pneumatic
Material Stainless Steel
TAG Membrance Control Valve Manual Flow Control Valve
Inquiry
Basic Info

    Model NO. : D001010002D

    Type : Self-Operated

    Material Quality : SS304,SS316L

    Standards : SMS,DIN,3A

    Seal : EPDM,PTFE

    Signal Range : 4~20mA

    Pressure : 1MPa

    Temperature : -10~150 Degree Celsius

    Flow Kvs : 1.6-100kv

    Outside Surface : Ra-1.6um

    Inside Surface : Ra-0.6um

    Size : 1"-5",Dn25-Dn125

    HS Code : 8481804090

    Trademark : XUSHENG

    Specification : ISO, 3A, SGS

    Transport Package : Shrink Wrap-Carton Case-Exporting Plywood Case

    Origin : Wenzhou City, China

Product Description

Products Name:Mannual Tri-Clamp Flow Regulating Valves with Stainless Steel Clamp

Regulating Valves With Stainless Steel Clamp
SMS 38.1MM Mannual TC Flow Regulating Valves



Technical Parameter

Nominal Diameter DN25-DN125,1"-5"
Connection Welding,Clamping,Threaded,according to Pipeline Connection
Nominal Pressure PN≤1.0Mpa
Valve Plug Seals Metal or Soft Sealing
Characteristics Equal Percentage or Linear
Measure Ratio Max.DN50-DN65 and above 30:1
Temperature Range -10~150 Degree Celsius



Selection Reference Data

DIN Size SMS/3A Flow Kvs m³/h The Area of Actuator cm² Effective Distance mm the working range of pneumatic(NC)
5 bar 10 bar
DN15 1/2" 1.6 120 7.5 1.7~2.1
2.5 1.7~2.1
DN20 3/4" 4 1.7~2.1
DN25 1" 6.3 240 15 0.3~1.1 0.9~3.3
10 0.3~1.1 0.9~3.3
DN40 1.5" 10 240 15 0.6~2.2 0.9~3.3
16 0.6~2.2 0.9~3.3
25 0.6~2.2 0.9~3.3
DN50 2" 16 240 15 0.6~2.2 0.9~3.3
25 0.6~2.2 0.9~3.3
35 350 1.4~2.3 2.1~3.3
DN65 2.5" 25 350 15 1.4~2.3 2.1~3.3
35 1.4~2.3 2.1~3.3
60 1.4~2.3 2.1~3.3
DN80 3" 35 350 15 1.4~2.3 2.1~3.3
60 1.4~2.3 2.1~3.3
80 1.4~2.3 2.1~3.3
DN100 4" 60 350 15 1.4~2.3 2.1~3.3
100 1.4~2.3 2.1~3.3



The Quality Requirement for Compressed Air Used in Actuator

Compressed Air Connection Air Pipe with Air Connection R1/8"(BSP)
Min.Working Pressure 0.4Mpa
Max.Air Supply Pressure 0.6Mpa
Max.Pellet Size 0.01MM
Max.Oil Content 0.08PPM
Dew Point 10ºC Lower Than Air Temepature or Lower
Max.Water Content 7.5g/g



Operatiing principles

Constant pressure valve operated by compressed air, automatically run without sensor on piping system ot other auxiliary instruments, and only one compressed air pressure regulating valve that maintains perssure stability can be realized the normal work of the valve.
Diaphragm slice and valve rod can be fit to transport product an pressure changes to make a quick response, and the corresponding change the valve stem position, in order to continue to keep the preset pressure vavle.
Constant pressure valve - V: inlet pressure constant , in conveying medium pressure higher than the set pressure under the condition of the valve opens, the transmission medium pressure decreases flow has become, conveying medium pressure is insufficient valve closed.
Constant pressure valve - A: outlet pressure constant, when transmitting medium pressure is higher than the set perssure under the condition of the valve will be closed, conveying medium pressure decreasees flow changes, conveying medium pressure is insufficient valve opens.





Applications

This valve has two styles:eletric-pneumatic control valve and manual control valve,used in automatic control system to control pressure,capacity,temperaure and tank level.
